QUARTER
MIDGET
CHASSIS SETUP MANUAL
Basic Car Setup -- 10 steps to
going FAST
|
STEP 1 |
Squaring up the car, Lead and Ackerman Steering
|
| STEP 2 |
Front axle Camber, Caster and Toe-in Settings
|
| STEP 3 |
Tire Size and Compound
|
| STEP 4 |
Tire location, Stagger and Tire Pressure
|
| STEP 5 |
Ride Heights and Tilt
|
| STEP 6 |
Coil Springs and Shocks
|
| STEP 7 |
Static Weight Settings and Cross Weights
|
| STEP 8 |
Panhard Bar Settings
|
| STEP 9 |
Dynamic Weight Transfer
|
| STEP 10 |
Track Testing - making it work on the track
|
 |
Deluxe
Looseleaf Manual |
|
32 pages of
detailed instructions |
|
Complete Setup
for any Coil Car |
|
Asphalt or
Dirt |
|
Fully Indexed
so you can go right to the settings |
| Tire
Charts for Vega and Hoosier |
| Shock
setting charts |
|
Car Charts for
track testing your car |
|
Parts Catalog
feature items |
NOW - includes
a laminated Gear Chart for DECO, HONDA,
World Formula and Animal
|
|
Honda
Motor Package
120
Honda Motor ------------------ $440.00
Clamp On Motor Gear Hub ------ 19.50
3 Hole Motor Gear -----------------
19.50
Split Axle Gear
---------------------- 19.50
Tailpipe, specify class ------------
45.00
#65 Jet, (#80 for 160 Class)
------ 5.25
One Quart of Power Plus --------
12.00
Total List
Price $560.75
120
Honda Package -------- $525.00
160 Honda Package -------- $550.00
Deluxe
Linkage Kit ----- $ 35.00
|
*SET UP & DYNO TUNE
MOTOR
Break in motor on Dyno prior to disassembly
*Remove muffler, air cleaner, gas tank, throttle
and pull start.
*Remove internal/external governor ,
plug hole
*Torque connecting rod bolts to custom
spec.
*Install side cover and torque bolts to
custom
specification.
*Rotate gearbox 90 degrees.
*Lap intake/exhaust valves for proper
seal.
*Install cylinder head and torque bolts
to custom
specification.
*Set valve clearances to custom
specifications.
*Remove choke assembly and plug hole.
*Replace carburetor main jet per Honda
rulebook
*Adjust coil position per custom
specification
*Modify starter cup per Honda rulebook.
*Remove on/off switch
Run motor on Dyno to
check settings
Add
$200.00 |
|
Honda Rebuild Kits
Rebuild your own Honda and Save!!
Flex Hone for 120 Honda -------- $35.00
Honda Ring
Set -------------------- 20.00
Valve
Springs, set of two -------- 5.90
Head Gasket
------------------------ 8.15
Valve Cover
Gasket -------------- 3.20
One Quart
Power Plus ------------ 12.00
Total List
Price
$84.25
|
120 Honda Rebuild Kit ---- $75.00
With Flex Hone for 160 Honda, 160 ring set
160
Head Gasket, springs and oil --
160 Honda Rebuild Kit ---- $80.00
|
|
